VW Polo Power Steering Fault
Mr G’s Volkswagen Polo was not in good shape. The steering felt heavy, power assistance had stopped working, and a warning light was showing on the dashboard.
The thing was… a ‘fix’ had already been carried out elsewhere. That included the replacement of a part, but it hadn’t solved the VW Polo power steering fault. The warning light remained, and the power steering never returned.
By the time Mr G contacted Ystrad Service Centre, he wanted a clear explanation. Not a hopeful part swap, but a definitive understanding of what was preventing the steering system from working properly. And a reliable fix.
The Volkswagen Polo was then brought to Ystrad Service Centre in Ystrad Mynach, serving Caerphilly and the surrounding areas, so the steering system could be assessed in detail by our VW specialists.
From there, attention turned to identifying what was holding the steering system back and what would be required to resolve the fault. This time, for good.
Initial VW Polo Power Steering Fault Evaluation Begins
When Mr G’s Volkswagen Polo arrived at Ystrad Service Centre, we already had a clear report of the symptoms: no power steering and a warning light on the dashboard. We then confirmed the same fault ourselves. The steering assistance was completely absent when manoeuvring the car, and the warning light was illuminated.
We then reviewed the background to the fault and the steering work that had already been carried out before the vehicle came to us. A steering pump and motor unit had previously been replaced, yet it hadn’t solved the VW Polo power steering fault.
Early checks concentrated on the steering system itself and the condition of the recently installed component. There were no signs of fluid leakage or disturbed wiring to the pump and motor unit. As nothing stood out during these checks, electronic testing was the next step.
The steering control module was accessed using Volkswagen dealer-level diagnostic equipment, where a single stored fault was identified:
- Fault code 00816 Power Steering Sensor (G250)
Fault code 00816 power steering sensor (G250) indicates a signal-related issue within the steering system. At this stage of the evaluation, however, the code alone did not explain why steering assistance had been disabled. It was not yet possible to determine whether the issue related to the sensor itself, pump compatibility, system configuration following installation, or another aspect of the steering system.
With the fault code recorded and the vehicle behaviour aligning with the symptoms experienced during testing, we moved on to the next stage of the diagnostic process to understand why the steering system had shut down and what was preventing assistance from returning.
Revealing the Cause of Fault Code 00816
Next, we moved into a deeper diagnostic phase focused on how the system was interpreting signals and configuration.
Each stage of testing was completed sequentially, allowing us to narrow the issue down methodically. Here’s the steps we took:
Step 1: Confirming electrical supply to the steering pump
We began by checking whether the steering pump and motor unit were receiving the correct electrical supply.
Using Volkswagen wiring information, the main power feed and ground circuits at the pump connector were identified and tested with the ignition switched on to confirm voltage and continuity.
What we found:
- Battery voltage was present at the steering pump.
- The ground circuit tested correctly.
- No faults were found in the electrical supply.
This confirmed that the pump and motor unit were being powered correctly, allowing us to rule out a supply-related issue at an early stage.
Step 2: Reviewing steering system communication and serial data
With the electrical supply ruled out, attention turned to how the steering system was reporting data back to the control module.
We connected our ODIS diagnostic tool and reviewed the fault memory within the steering control module. We also examined the serial data being reported by the system.
What we found:
- The steering control module was active and responsive.
- Communication with the vehicle network was intact.
- The signal from the power steering sensor (G250) was missing or invalid.
Because the system could not interpret this sensor signal, steering assistance had been disabled as a safety measure. This ruled out a complete control module failure and pointed towards a signal-related or configuration-related issue.
Step 3: Checking steering pump compatibility
As a steering pump and motor unit had already been fitted before the vehicle arrived with us, compatibility became the next point to confirm.
We checked the part number fitted to the vehicle against Volkswagen’s parts database using the VIN. We also reviewed the steering system variants used on this model, as different pump configurations were used depending on specification.
What we found:
- The pump and motor unit fitted did not match the original specification for this vehicle.
- The internal configuration of the unit did not align with what the steering control module expected.
This mismatch explained why fault code 00816 power steering sensor (G250) was being logged and why the steering system was unable to process the sensor signal correctly.
Step 4: Confirming coding and configuration status
Even when the correct hardware is installed, steering pump units must be configured and coded to the vehicle before they will operate correctly.
Using ODIS, we accessed the pump’s control module and checked whether the coding and configuration process had been completed following installation.
What we found:
- The replacement pump and motor unit had not been coded to the vehicle.
- Without correct coding, the steering system could not interpret the sensor signal.
This confirmed the underlying cause of the fault. The previously fitted pump and motor unit was both incompatible with the vehicle and left uncoded, resulting in fault code 00816 and the continued loss of power steering assistance.
VW Power Steering Repair Completed After Correct Setup
Once the underlying cause of the steering fault had been confirmed, we spoke with Mr G to explain what the power steering system required and how the repair would be carried out. With everything agreed, we moved ahead with restoring the VW Polo’s power steering correctly.
- The correct steering pump and motor unit was selected by matching the vehicle’s VIN against Volkswagen’s parts data, ensuring the replacement aligned with the original specification fitted to this model.
- Before installation, the surrounding components were checked. Wiring, connectors, and hydraulic lines around the rear-mounted steering fluid tank were inspected to confirm they were in good condition and free from contamination or damage.
- The incompatible pump and motor unit was removed, and the correct OEM replacement installed. All fixings and connections were secured in line with the manufacturer’s torque specifications.
- The power steering hydraulic system was refilled with the specified fluid and bled following Volkswagen’s recommended procedure to remove any trapped air.
- Using ODIS, Volkswagen’s dealer-level diagnostic tool, the new pump was coded and configured to the vehicle. This ensured the steering control module could recognise the replacement unit and operate the system correctly.
- The stored fault code was cleared, and the system was tested. The steering warning light switched off, power steering operation returned, and the vehicle performed as expected during post-repair checks.
Power Steering Restored and Warning Light Gone
After the correct pump and motor unit had been installed and the system configured, the Volkswagen Polo’s power steering began operating normally again. The steering warning light was gone, and steering effort returned to expected levels, restoring confidence behind the wheel.
Earlier repair work had not resolved the issue, but our structured technical evaluation identified what the steering system was lacking and allowed the repair to be completed successfully. This confirmed that correct configuration and system compatibility were essential to restoring proper steering function.
While the work was being carried out, Mr G was able to stay mobile using our free courtesy car. The repair was completed with Ystrad Service Centre’s 12-month parts and labour guarantee, providing reassurance once the vehicle was returned to service.
